wooden case or as your request for ZNCL-D Intelligent Multipoint Magnetic Stirrer
Shipped in 7 days after payment
Henan Lanphan ZNCL-D intelligent multipoint magnetic stirrer is used for liquid mixture in lab. Usually used for stirring and heating low viscosity liquid or solid-liquid. It's fundamental is repellence and attract of magnet. The magnet drive the rotor in the beaker. Match up with the heating control part, heat and control the sample temperature as requirements, so that to ensure liquid mixture reach to experiment requirement.
ZNCL-D intelligent multipoint magnetic stirrer makes use of the feature of same sex repel each other of magnetic material, by continuously changing the polarity of both ends of substrate to make magnetic stirrer bar rotate, and by the rotating of magnetic stirrer bar to make sample uniformly mixing; by bottom temperature control plate to heat the sample, along with the rotating of magnetic stirrer bar to make sample uniformly heated and reach pointed temperature, in order to apply to wider sample treatment process. In general, ZNCL-D intelligent multipoint magnetic stirrer has two functions of stirring and heating:
1st function: make reactant mix uniformly, and make temperature balance; 2nd function: quicken reaction speed or evaporation speed, shorten reaction time.
Product features of ZNCL-D intelligent multipoint magnetic stirrer: 1. Multipoint heating and stirrer, 5 point or 9 point 2. All point can be stirred synchronous or by single point. 3. Digital display stirring speed. 4. Brushless motor, lower noise, no spar and long lifetime. 5. Ceramic or stainless steel heating plate, beautiful and anti-corrosion.
6. Unique Temp. control system, surface Max. Temp. could reach 350 degrees Celsius.
Intelligent multipoint magnetic stirrer
5 point/9 point
5 point/9 point
Surface Temp. 350*0
5 point: 230ramx230mm 9 point: 280mmx280ram
5 point: 600W 9 point: 750W
Intelligent PID control
Temp, control accuracy
Heating plate material
Ceramic or stainless steel
5 point: 5x250ml 9 point: 9x250ml
0-2000rpm Speed digital display
5 point: 430x270xl50mm 9 point: 500x330x150mm
5 point: 480x320x200mm 9 point: 550x380x200mm
5 point: 7000±200g 9 point9500±200g
ZNCL-D magnetic stirrer is widely used in oil, chemical, medicine, environment, biochemistry, education laboratories, etc.
Packaging & Shipping
Package: exported wooden case package.
Shipping: according to quantity, usually we use International Express, Air and Sea transportation.
1. Multipoint heating and stirrer, 5 point or 9 point 2. All point can be stirred synchronous or by single point. 3. Digital display stirring speed. 4. Brushless motor, lower noise, no spar and long lifetime. 5. Ceramic or stainless steel heating plate, beautiful and anti-corrosion. 6. Unique Temp. control system, surface Max. Temp. could reach 350 degrees Celsius.
Pre-sale Service 1. Provide 24-hour technical consulting reply; 2. Provide professional quoted price; 3. Provide detailed product performance specification; 4. According to product’s using condition, technicians will offer rationalization proposals to assist clients to select proper product types. In-sale Service 1. Begin to supervise from raw material, its qualified rate can reach to 100%; 2. Whole manufacturing process are in strict accordance with promised procedure requirements, product qualified rate can reach to 100%; 3. Provide product’s inspection record of key junctures to customers; 4. Provide production schedule photos to customers at regular intervals; 5. Provide transportation schedule information to clients timely. After-sale Service 1.Under the premise of correct installation, normal maintenance and using, we guarantee one-year warranty period; 2. When warranty period has expired, our sold products enjoys lifetime guarantee repair, we only charge cost price for changing product’s standard component and sealing component; 3. During installation and adjustment period, our after-sale service staff will communicate with customers frequently to know product’s running state in time. Assist customers to install and adjust products until customers are satisfied; 4. If product has malfunction during operation period, we’ll offer you satisfied answer in time. We’ll reply you within 1 hour and provide solution or send staff to spot within 24 hours after receiving maintenance notification. 5. Lifelong free technical support. Conduct satisfaction survey and inquiry equipment running condition to clients by telephone or e-mail semiannually from the first day of equipment running, put on records of acquired information.
1.What’s your MOQ? One set at present. 2. What kind of payment term do you accept? Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal. 3. How will you delivery these goods? It will be decided according to your quantity. Normally we will choose International Express, Air and sea. 4.What plug standard it use? European standard, American standard, German standard, etc, we can custom-made according to your requirement. 5.How about the voltage? 110V/60HZ, 220V/50HZ, we can custom-made according to your requirement.
